Send InquiryBelt Conveyor System
Price 35000 INR/ Unit
MOQ : 1 Unit
Belt Conveyor System Specification
- Thickness
- Belt thickness 5 mm (customizable)
- Features
- Low maintenance, smooth noise-free operation, modular design
- Belt Type
- Flat belt
- Power Source
- Electric
- Surface Finish
- Powder coated or painted
- Material
- Mild steel, stainless steel, aluminum (frame); rubber/PVC (belt)
- Type
- Belt Conveyor System
- Structure
- Mild steel or stainless steel frame
- Belt Conveyor
- Included, rubber or PVC belt type
- Roller Conveyor
- Optional customization
- Vertical Conveyor
- Available as optional configuration
- Pneumatic Conveyor
- Not integrated; mechanical belt system
- Resistant Feature
- Corrosion & abrasion resistant components
- Load Capacity
- 50-100 kg per meter (customizable)
- Voltage
- 220-415 V AC, 50 Hz
- Power
- 1-5 HP (Depending on conveyor length and load)
- Speed
- 0.5-2 m/s (variable via drive control)
- Usage & Applications
- Industrial material handling, packaging, assembly lines, warehouses
- Belt Width
- 300 mm to 1200 mm as per requirement
- Maximum Incline
- Up to 20 degrees (optional)
- Safety Features
- Emergency stop switch, safety covers, side guards
- Noise Level
- < 65 dB (low noise operation)
- Conveyor Height
- Adjustable from 650 mm to 1200 mm
- Operating Temperature
- 0 to 60C
- Installation
- On-site installation available
- Drive Type
- Gear motor with reduction gear box
- Total Length
- Customizable from 2 to 30 meters
Belt Conveyor System Trade Information
- Minimum Order Quantity
- 1 Unit
- Supply Ability
- 3 Units Per Month
- Delivery Time
- 8-10 Days
